Fully offline: Supports the standard SIP protocol, allowing operation without any computer software support. After registration, it can directly engage in two-way calls or broadcast announcements with SIP-enabled phones.
Intercom Function: You can call a designated SIP phone host via buttons, or call the SIP-608Z terminal from any SIP system phone host. The intercom operates in full-duplex mode and is equipped with an echo cancellation function.
Multicast Function: It can receive RTP multicast data playback from SIP phones and output it through the speakers or line outputs of the SIP608Z, either via the built-in speakers or line outputs.
Broadcasting: Supports our company's proprietary broadcast protocol, allowing operations such as broadcast announcements and scheduled bell ringing through our broadcasting software.
Scalable: Fully compatible with two-way radio broadcast terminals, as well as other two-way radio terminals in standard SIP systems, allowing for the free choice of building a complex SIP two-way radio system.
Technical parameters
Network Interface: 10/100Base-TX adaptive network, RJ45 interface, transmit/receive data indicators.
MIC Input: Comes with a high-performance microphone, frequency range 70～12.15 kHz;Typical amplitude: 50 mVpp, signal-to-noise ratio: 68 dB.
Audio Output: Comes with a built-in waterproof 3W speaker.
Intercom modes: Supports quiet mode and noisy mode, button-based answering and automatic answering, on-site disconnection and remote disconnection, etc.
Input voltage: DC 9~24V
Power consumption: Static <300mW
Operating temperature: -40°C to 85°C
Specifications and dimensions: 210×120×50 mm (excluding the microphone stand)
